These innovative measuring instruments are suitable for almost all production processes in the food and beverage and in the life science industries and are particularly advantageous in applications where the density (or concentration, Brix, Plato, Proof or BaumƩ value) must be determined at the same time as the flow rate.
Emersonās hygienic Micro Motion H-Series and G-Series deliver superb measurement. Their superior flow and density performance as well as reliability in a compact design make them ideal for use in hygienic process environments. A wide portfolio of transmitters ensures maximum compatibility with any control system. Both sensor and transmitter can be adapted to almost any individual requirement thanks to a wide range of configuration options.
Hygienic certifications now also for Micro Motion G series
- Both the H series and the G series are now 3A/EHEDG certified, giving the perfect choice for all hygienic applications between precision, installation size, cost, connectivity, and other process requirements
- One device for different applications: Mass and volume flow measurement, density measurement, measurement of liquids and slurries or even gases
- Superior measuring accuracy of up to Ā±0,05 % (liquid mass control) and up to Ā±0,0005 g/cm3 (density control)
- Smart Meter Verificationā¢ provides advanced diagnostic of the meter functionality
- The G-series is the cost-effective and ultra-compact all-arounder for the most current applications
- The H-series offers improved specifications for the most demanding requirements in terms of measuring accuracy, turndown, pressure, and
temperature stability - Hygienic design with all stainless steel 316L, surface quality 0.8 or 0.4 Ī¼m
- The nominal widths from DN25 to DN100 and a temperature range up to 204 Ā°C mean that even exceptional requirements can be met.
Micro Motion Coriolis Flow Meters complete Anderson-Negeleās portfolio
Every drop counts: From reception to the various processing and refinement processes through to CIP control, and for media of most different consistencies and viscosities ā accurate flow control is a must. With an extensive range of individually configurable sensors, hygiene specialist Anderson-Negele offers the most suitable, hygiene-compliant flow control solution for almost any application. The field proven range includes magnetic-inductive and turbine sensors and ultrasonic and calorimetric flow switches. The sensors developed in-house and produced in the company’s own factories now include temperature, pressure, continuous level, point level, turbidity, conductivity, load cells and flow meters in a wide variety of designs. Emersonās hygienic Micro Motion devices complete this portfolio as part of a global sales partnership.
