Reducing Your Carbon Footprint With Heat Exchangers

Reducing Your Carbon Footprint With Heat Exchangers
Around the world, private companies and government agencies are looking to reduce the greenhouse gas (GHG) emissions associated with their activities, including increasing their use of renewable and low-carbon energy sources and improving the energy efficiency of their processes.

Energy efficiency represents more than 40% of the emissions abatement needed by 2040, according to the International Energy Agency (IEA) Sustainable Development Scenario1. The IEA says, ‘Energy efficiency is the “first fuel”: reining in the scale of this unprecedented challenge, supporting net zero energy goals at lower costs, and delivering a wide array of benefits for society.’

Furthermore, ‘According to the IEA Efficient World Scenario, currently existing cost-effective technologies are sufficient to double global energy efficiency by 2040.’ Heat exchangers are just such an existing, cost-effective technology. Technologically proven for over a century, developments in materials and design mean that many types of heat exchanger, such as those utilizing corrugated tubes and energy recovery, are now more energy efficient than ever before.

The biggest efficiency benefits of heat exchangers come about when they facilitate the reuse of as much of the thermal energy generated or used during a process (such as heating, cooling, pasteurization, evaporation, etc.) as possible. Distributing heat more efficiently throughout production facilities has been recognized as a key factor in improving efficiency and reducing greenhouse gas (GHG) emissions in industries including chemical refining, water treatment and manufacturing.

Many processes require heat, but not all of them utilize all of it. For example, a process using steam at 100°C or more may result in a hot water stream with a temperature of 80-90°C. In some cases, this will be reheated in a continuous cycle, but in the least efficient situations it may simply be dumped, perhaps requiring cooling before it can be discharged. Water with this temperature profile has a range of potential uses, including pasteurization and low temperature evaporation. Rather than continually heat and then dump process hot water, it makes far more sense to reuse it where possible, by transporting it to where else it is needed in the facility.

Examples of heat recovery with heat exchangers

The first typical example can be seen in food production, if we imagine a product that needs to be pasteurized. The product needs to be heated to the necessary temperature to achieve pasteurization, then rapidly cooled to maintain shelf life and quality. This is achieved through the use of two heat exchangers. The first uses hot water to raise the temperature, while the second uses chilled water to cool the product down again. In the second process, the temperature of the cooling water is increased significantly. There are three options for dealing with this heated water: discard or discharge it elsewhere; cool it again for re-use; or cool it again for re-use but use some of the heat it contains towards the heat required for the pasteurization phase. This third option utilizes heat recovery or heat regeneration, reducing the amount of new energy required for the subsequent first heating phases.

A second example shows how heat left over from one process can be recaptured to be used elsewhere. Many anaerobic digestion (AD) plants use heat exchangers to pasteurize the digestate produced during the AD process, so that it can be sold as an agricultural fertilizer. The ‘surplus’ heat which is generated after the system has been running for two hours is used to preheat the digestate, reducing total heat load and improving overall plant efficiency by increasing the amount of generated energy, which is available for export or other uses, as opposed to being required for pasteurization.

Finally, combining multiple heat exchanges can often provide the greatest energy benefits, for example, in a multi-effect evaporation system such as the HRS DCS Digestate Concentration System. This uses heat exchangers and evaporation to reduce the volume and increase the concentration of sludges and digestate. The first evaporation stage heats liquid digestate and uses a cyclone separator; the steam produced from this first cycle (usually available at 70˚C) is then used as the heating media for the second effect, whereby the process is repeated. The subsequent steam (usually available at 60˚C) is then used as the heating media for the third cycle. The number of effects is determined by the level of dry solids required and the amount of surplus heat available, up to a maximum of four cycles. After the final stage the steam is condensed back to water and this heat is used to pre-heat the incoming product before the first stage of evaporation.

Heat recovery is not limited to systems dealing with liquids. HRS recently supplied a large G Series gas-to-gas heat exchanger to recapture heat from the high temperature exhaust gases leaving a large chemical reactor. This recovered heat is then used to help pre-heat the chemicals entering the reactor to around 500 °C. As well as helping to improve energy efficiency at the plant, the new unit has been designed to cope with challenging operating conditions in order to provide a suitable working life.

These examples show that where the situation allows, HRS corrugated heat exchangers have significant potential to reduce the energy consumption (and therefore GHG emissions) of thermal processes in a wide range of industries. The capital costs of including energy recovery in a heat exchanger system is likely to be higher than similar systems without heat recovery, but these will be recovered over the working life of the unit, particularly at today’s high energy prices.
