Crucial Temperature Control in Pharma Manufacturing

Crucial Temperature Control in Pharma Manufacturing
HRS Heat Exchangers have helped a leading Australian pharmaceutical company expand its production capacity by supplying a bespoke system that controls the temperature of solution materials used in capsule manufacturing.

Mayne Pharma, a listed Australian company, commercializes branded and generic pharmaceuticals in a range of product areas. Its GMP accredited manufacturing facility is located in Salisbury, South Australia, approximately 12 miles from Adelaide, where it produces tablets, capsules, liquids, and creams.

Capsules are a popular method of drug delivery, comprising of two-piece dissolvable outer shell containing miniature pellets which carry the active ingredients. The pellets are prepared using a fluid bed dryer in order to reduce moisture content and are sometimes spray-coated with a solution containing key ingredients. The spray-coating solutions use an alcohol-based formulation to ensure correct mixing and maintenance of the fundamental chemical properties.  The solutions must be prepared and applied within a tight temperature range.

Mayne Pharma wanted to expand and upgrade its existing production capacity for capsule production by adding a third fluid bed dryer and the associated equipment, whilst simultaneously improving temperature regulation to its existing lines. HRS Heat Exchangers was asked to provide a quotation for a hot water heater to support the new line, but quickly realized that a turnkey package offering active heating or cooling as required would provide a much better solution.

“The alcohol for the solutions is drawn from our outside tank farm,” a spokesperson for Mayne Pharma explained. “One of the issues with the old systems was that on hot days the factory had to wait for the alcohol to cool down before mixing the solutions, which could sometimes take hours. The HRS solution means that we can actively cool it if we need to. Alternatively, if we bring in the alcohol on a cold day, we can heat it up as necessary.”

The solution produced by HRS is a heater/cooler with the ability to reduce hours of cooling time to less than 60 minutes. Due to space constraints in the existing factory and the requirement to connect various pieces of equipment, the unit was supplied on a compact skid with integrated controls and automation of both heating and cooling processes. Other challenges faced by HRS Engineers were uncertainties about heat transfer in the existing tanks and having to overcome unknown pressure losses in a small jacket annulus which would otherwise affect the performance of the unit.

The HRS unit utilizes two K Series multi-pass corrugated tube heat exchangers to maintain the solvent temperature at 25 °C or 30 °C as required. The hot water loop is composed of one heat exchanger, a centrifugal pump, safety features, and the necessary ancillaries such as a pressure gauge, temperature transmitter, and manual valves.

“The service water is recirculated in a closed loop with the selected solution tank to heat the solvent from 15 °C to the target temperature,” says Ella Taghavi, Technical Sales Engineer at HRS Heat Exchangers. “The process is controlled by temperature transmitters and an autonomous control system and given the importance of the temperature in the process; product temperature is also monitored via a secondary control loop with transmitters located on each solution tank.”

Moreover, the cooling section is designed to maintain the product temperature at the targeted set point. Incoming service water from a buffer tank is cooled using chilled water at 6-10 °C from elsewhere in the factory using several passes through the second heat exchanger. “The tank jacket service water is recirculated in a closed loop with the selected solution tank to cool the solvent from 40 °C to the target set temperature of 25 °C or 30 °C,” adds Ella. Again, temperature transmitters control the process via an autonomous control loop.

Despite the Covid-19 pandemic, the process of manufacturing, installing, and commissioning the unit ran smoothly, taking less than six months from the order being received to the unit being fully operational. “Covid-19 meant that we weren’t able to undertake Factory Acceptance Testing (FAT) at HRS’s manufacturing facility in Spain, but as it was such a straightforward job, we wouldn’t have insisted on this anyway,” said the spokesperson. “We undertook the commissioning on site with remote support from HRS’s Engineer Ella Taghavi in Melbourne, but apart from a couple of phone calls nothing else was required.”
