Reed Level Transmitter Suitable for Food

14 Jan 2020  |
WIKA has expanded its range of level transmitters with reed measuring chain by adding the model FLR-F for food applications.

The instrument has an electropolished surface with a roughness of < 0.8 µm Ra and is available with application-specific process connections such as TriClamp.

The level transmitter works on the float principle with magnetic transmission. It measures the level reliably, even with foaming, and can additionally output a temperature value. The reed contacts in the guide tube (up to six metres long) can be arranged as a quasi-continuous level measurement.

The model FLR-F is also available in a version with a head-mounted transmitter for different output signals and communication protocols. Furthermore, the instrument can be supplied with a removable float limitation and FDA-compliant sealing or in an ATEX variant for applications in which pipes are cleaned with flammable media.

Share this article

This article is published by

As a family-run business acting globally, with over 11,000 highly qualified employees, the WIKA group of companies is a worldwide leader in pressure and temperature measurement. The company also sets the standard in the measurement...
