Hermetic Pump Solutions for Cryogenic Liquid Gases
Hermetically sealed and reliable pump solutions are crucial for handling these media. Low temperatures, high vapour pressure and fluctuating operating conditions place particular demands on pumping technology and plant safety. HERMETIC Canned Motor Pumps enable safe and leak-free operation even under demanding cryogenic process conditions.
Things to Know About LNG and LPG
- LNG (methane)Boiling point: approx. −162 °C
Cryogenic, liquefied natural gas
Significantly reduced transport and storage volume
High demands on materials and leak-tightness - LPG (propane/butane)Liquefaction occurs even at moderate pressures
Typical components: propane and butane
Used in industry, energy supply and transport
High vapour pressure and varying operating conditions
Manufacture of Chemicals
Hermetic pumping of methane and hydrogen mixtures in petrochemical processes under cryogenic conditions. (e.g. ethylene, urea, HDPE, LLDPE, LDPE, butadiene or rubber)
Application: LNG and LPG
- RequirementMedium: Methane and hydrogen
Delivery rate: 10.6 m³/h
Pumping head: 151 m
Operating temperature: –98.1 °C
Advantages: Reliable operation at low temperatures and high vapour pressure - HERMETIC SolutionsPump: CAMTV 32/5+0
Motor: N54p-2
Pump type: Vertical multi-stage Canned Motor Pump
Speciality: Low viscosity (0.07 CP), high vapour pressure of 32.2 bar and low temperature of the medium
Manufacture of Speciality Chemicals and Polymers
Production of high-quality speciality chemicals and polyolefins, including HDPE, mLLDPE, PE100+ polyethylene for gas pipelines, POE, alpha-olefins and UHMWPE. Production takes place under cryogenic conditions, with high standards of operational safety and process stability.
Application: LNG and LPG
- RequirementMedium: Methane, hydrogen and ethylene
Delivery rate: 153 m³/h
Pumping head: 129 m
Operating temperature: –98.7 °C
Advantages: Reliable operation at low temperatures and high vapour pressure - HERMETIC SolutionsPump: CAMFTVmu 60/2
Motor: N74rm-2
Pump type: Vertical multi-stage Canned Motor Pump
Speciality: By-pass pipe for safe operation and to prevent vapourisation; magnetic bearing; low medium temperature
Can’t Find Your Application Here?
We’ll work with you to develop a suitable pump solution for your specific process requirements. Thanks to our many years of experience in handling critical media, we can also produce bespoke designs and specialised solutions.
