Pump Series made of Investment Cast Stainless Steel Increases Service Life with Maximum Efficiency

Pump Series made of Investment Cast Stainless Steel Increases Service Life with Maximum Efficiency
11 Feb 2020  |
Especially when pumping chemically aggressive and abrasive waste water, as well as liquid chemicals, pumps must be particularly resilient and robust.

A common problem is that the shaft seal and cable inlet are attacked and destroyed by the fluids. This causes the medium to enter the motor housing, which – at worst – can lead to a total failure of the pump. In addition, the non-resistant metallic components corrode through contact with the aggressive media, which reduces the performance of the pump and can also cause a defect. HOMA Pumpenfabrik GmbH has therefore developed a comprehensive range of stainless steel submersible pumps. The individual series CH, CTP, CMX, CV, CVX, and CK are equipped with discharge connectors from 2″ to DN 150. The CH430 series is characterized by a compact and robust design, which allows flexible use in the chemical industry and the transport of bilge water in shipping. The units are made of resistant, investment cast stainless steel, which means vibrations are absorbed more effectively, with less resultant stress on the bearing and mechanical seal. This increases the service life and considerably reduces maintenance intervals.

“In order to reliably and safely convey chemical fluids and wastewater contaminated with chemicals, the pumps used must be particularly resilient,” explains Stephan Wild, responsible for technical project planning at HOMA Pumpenfabrik GmbH. “If the shaft seal or cable inlet is decomposed by the medium, the aggressive chemical fluid gets into the motor compartment, ultimately causing the pump to fail.” Moreover, non-resistant metallic components may corrode due to contact with the medium being handled, resulting in reduced functionality or a pump defect. The various stainless steel submersible pumps in the CH, CTP, CMX, CV, CVX and CK series from HOMA Pumpenfabrik GmbH – designed with discharge connectors from 2″ to DN 150 – are suitable for continuous operation in the chemical industry and for the disposal of chemically contaminated wastewater. “The highly resistant investment cast stainless steel used makes the series resilient against aggressive fluids,” Mr. Wild adds. “In addition, contaminated water containing solids such as sand and sludge can also be pumped. With the CH430 series, the contaminants can have a particle size of up to 10 mm.” Due to its compact and robust design, this stainless steel unit is versatile and can be installed and operated on either a stationary or a mobile basis. This makes it ideal for use in the chemical industry and for the disposal of abrasive, chemical wastewater.

Use of high-grade stainless steel ensures trouble-free pumping

To ensure continuous pumping, individual components of the CH430 series, such as the motor housing, impeller, and pump housing, are made of stainless steel 1.4436. The motor shaft is manufactured with stainless steel 1.4462, while the various mechanical connecting parts use stainless steel 1.4571. The mechanical seal is available as an encapsulated version so that the spring of the seal does not come into contact with the pumped medium. This eliminates the need for bellows, which tend to be a fragile component. The strainer is installed on the pump housing and the pump block, which is made of highly resistant investment cast stainless steel, is fully floodable and sealed against pressurized water. This allows aggressive media and chemicals with a pH value of 3 to 14 to be conveyed. Liquids can be transported at temperatures of up to 40 °C. Levels of 60 °C can also be sustained for brief periods. Thanks to the investment cast stainless steel and the accordingly robust design of the pump, vibrations are absorbed more effectively, resulting in low susceptibility to failure and long service life. The design also subjects the bearing and mechanical seal to less stress: “This significantly reduces the maintenance intervals and increases the service life,” explains Mr. Wild. The submersible pumps are also available in an explosion-proof design in line with the ATEX Directive II 2 G Ex c d II B T4(T3).

High efficiency and automatic monitoring via app

The unit features a high degree of efficiency: “The hydraulic requirements are factored in at the project planning stage using flow simulation software, in order to guarantee optimum pump design. This results in early insights into the achievable efficiency level, which is reflected in the low energy consumption of the pumps. Of course, it depends on the respective application scenario,” comments Mr. Wild. In addition to the calculation software, the company’s own stator winding system influences the result and contributes to the high-efficiency levels. The components of the series can, therefore, be adapted to specific order scenarios, as requested by the customer.

The pumps can be regulated and monitored fully automatically by an additional controller: “Faults during a pumping process are automatically reported by the controllers to a mobile device via an app, and can, therefore, be rectified promptly,” reports Mr. Wild. The fill level in the sump, the current measurement function and the thermal condition of the winding can be monitored. At the same time, maintenance intervals, delay times, start-up delays and rotational direction detection are displayed: “This ensures trouble-free operation when pumping chemically aggressive, abrasive media and chemicals,” Mr. Wild summarises.
